Beauvais, Saint-Pierre
BEAUVAIS

Building Data for Beauvais, Saint-Pierre

  •
  • Type: Cathedral
  • Affiliation:
  •
  • Region: Picardie
  • Department: Oise
  • Coords: 49.429, 2.0800
  •
  • Surveyed: 1980-83, 2003, 2011, 2015

Map

Virtual Tour

Timeline and building units for Beauvais, Saint-Pierre A 'building unit' is an arbitrary unit of work based on bulk billing techniques used by quantity surveyors. The unit is small enough to provide realistic figures in the small churches without becoming too huge in the large. Six units would pay for one small vaulted bay in an aisle about 3 metres square, or a small first-floor gallery. Such a bay would consist of an external wall with a small window, half of two columns about 3 meters tall, the floor and footings under them and the vault and roof overhead.
X

A 'building unit' is an arbitrary unit of work based on bulk billing techniques used by quantity surveyors. The unit is small enough to provide realistic figures in the small churches without becoming too huge in the large. Six units would pay for one small vaulted bay in an aisle about 3 metres square, or a small first-floor gallery. Such a bay would consist of an external wall with a small window, half of two columns about 3 meters tall, the floor and footings under them and the vault and roof overhead.

info

gray gray 457
1220		 486
1230		 330
1240		 gray
1050 1220s 1230s 1240s 1250

Phases for Beauvais, Saint-Pierre The building sequence is based on my on-site analysis of the construction history, using the techniques developed on the cathedral of Chartres called toichology, and described in a number of publications. The analysis of some of the smaller churches are more approximate than I would like, and need further analysis. <p>I have used 'phase' rather than 'campaign' to to identify a contiguous zone with similar elements. A campaign would be defined by recognisable breaks and construction joints in the fabric: there may be a number of phases within a campaign. One benefit is that separate programs by subcontractors, such as carvers, may be isolated, which is particularly useful in complex sections, such as portals. <p>Every phase has been assigned to a decade, so there may be more than one phase in a decade. <p>While this is certainly imperfect, it will allow us to explore all the data, including costs, across time. This is an on-going process, so as the data continues to be analyzed, the chronology and costing analysis will be further refined, and the synopsis updated. <p>Clicking on any of the decade graphics will display all buildings that had work being done during that decade.
X

The building sequence is based on my on-site analysis of the construction history, using the techniques developed on the cathedral of Chartres called toichology, and described in a number of publications. The analysis of some of the smaller churches are more approximate than I would like, and need further analysis.

I have used 'phase' rather than 'campaign' to to identify a contiguous zone with similar elements. A campaign would be defined by recognisable breaks and construction joints in the fabric: there may be a number of phases within a campaign. One benefit is that separate programs by subcontractors, such as carvers, may be isolated, which is particularly useful in complex sections, such as portals.

Every phase has been assigned to a decade, so there may be more than one phase in a decade.

While this is certainly imperfect, it will allow us to explore all the data, including costs, across time. This is an on-going process, so as the data continues to be analyzed, the chronology and costing analysis will be further refined, and the synopsis updated.

Clicking on any of the decade graphics will display all buildings that had work being done during that decade.
1220

Phase 1 - 1220 - chapels (b) - 187 Units


Foundations for chapels and their bases
1220

Phase 2 - 1220 - chapels (s) - 270 Units


Chapels to sills
1230

Phase 3 - 1230 - choir aisle (s) - 240 Units


Choir walls to sills, rooms
1230

Phase 4 - 1230 [1235] - choir (a-) - 246 Units


Choir lower capitals in aisles and sacristy
1240

Phase 5 - 1240 [1240] - choir (ag) - 330 Units


Choir piers and aisle vaults, aisle upper gallery
Later

Phase 6 - Later


Continuation into aisle triforium, arcade capitals and vauts
