Angicourt, Saint-Vaast
ANGICOUR

Building Data for Angicourt, Saint-Vaast

  •
  • Type: Abbey
  • Affiliation: Benedictine
  •
  • Region: Picardie
  • Department: Oise
  • Coords: 49.311, 2.5039
  •
  • Surveyed: 1977, 1980-83, 2014

Map

Click and drag to rotate; Roller to zoom; Arrow keys to pan

Virtual Tour

Timeline and building units for Angicourt, Saint-Vaast A 'building unit' is an arbitrary unit of work based on bulk billing techniques used by quantity surveyors. The unit is small enough to provide realistic figures in the small churches without becoming too huge in the large. Six units would pay for one small vaulted bay in an aisle about 3 metres square, or a small first-floor gallery. Such a bay would consist of an external wall with a small window, half of two columns about 3 meters tall, the floor and footings under them and the vault and roof overhead.
X

A 'building unit' is an arbitrary unit of work based on bulk billing techniques used by quantity surveyors. The unit is small enough to provide realistic figures in the small churches without becoming too huge in the large. Six units would pay for one small vaulted bay in an aisle about 3 metres square, or a small first-floor gallery. Such a bay would consist of an external wall with a small window, half of two columns about 3 meters tall, the floor and footings under them and the vault and roof overhead.

info

gray gray 58
1160		 gray 14
1180		 75
1190		 gray 4
1240		 gray
1050 1160s 1180s 1190s 1240s 1250

Phases for Angicourt, Saint-Vaast The building sequence is based on my on-site analysis of the construction history, using the techniques developed on the cathedral of Chartres called toichology, and described in a number of publications. The analysis of some of the smaller churches are more approximate than I would like, and need further analysis. <p>I have used 'phase' rather than 'campaign' to to identify a contiguous zone with similar elements. A campaign would be defined by recognisable breaks and construction joints in the fabric: there may be a number of phases within a campaign. One benefit is that separate programs by subcontractors, such as carvers, may be isolated, which is particularly useful in complex sections, such as portals. <p>Every phase has been assigned to a decade, so there may be more than one phase in a decade. <p>While this is certainly imperfect, it will allow us to explore all the data, including costs, across time. This is an on-going process, so as the data continues to be analyzed, the chronology and costing analysis will be further refined, and the synopsis updated. <p>Clicking on any of the decade graphics will display all buildings that had work being done during that decade.
X

The building sequence is based on my on-site analysis of the construction history, using the techniques developed on the cathedral of Chartres called toichology, and described in a number of publications. The analysis of some of the smaller churches are more approximate than I would like, and need further analysis.

I have used 'phase' rather than 'campaign' to to identify a contiguous zone with similar elements. A campaign would be defined by recognisable breaks and construction joints in the fabric: there may be a number of phases within a campaign. One benefit is that separate programs by subcontractors, such as carvers, may be isolated, which is particularly useful in complex sections, such as portals.

Every phase has been assigned to a decade, so there may be more than one phase in a decade.

While this is certainly imperfect, it will allow us to explore all the data, including costs, across time. This is an on-going process, so as the data continues to be analyzed, the chronology and costing analysis will be further refined, and the synopsis updated.

Clicking on any of the decade graphics will display all buildings that had work being done during that decade.
1160

Phase 1 - 1160 [1167] - east, south (a-) - 25 Units


East and south walls over footings to arches into nave aisles; if the south was higher than the north then the splay on the south plinth marks the junction.
1160

Phase 2 - 1160 [1168] - east, south (c) - 33 Units


East and south walls and chapel to vaults with capitals.
1180

Phase 3 - 1180 - nave walls - 14 Units


Nave aisles walls in complex campaigns before interior because did not design layout with the arrangement for the high vault in mind.
1190

Phase 4 - 1190 [1195] - nave (a) - 35 Units


Nave aisle drums and piers for a six-part vault; height low to suit the lower aisle entries from the east; west portal. Along south walls can see a joint just above floor level that steps up into the apse and includes the crossing pier to aisle caps. . Another lies above the lintel over the door and over the springing stone. A third lies over the imposts. Follow in different designs for the windows.
Load More...
1190

Phase 5 - 1190 [1197] - nave (c) - 40 Units


Nave clerestory in three campaigns with six-part vaults and flyers.
1240

Phase 6 - 1240 [.] - west porch - 4 Units


West porch
